Disce plus| Pars non | No.of Poles | Plenus load amps | Resistentia amps | Clausum rotor Amps @ CCXL | Intentione coil |
| Dma130 | 1 | 30 | 40 | 180 | 24 |
| DMB130 | 1 | 30 | 40 | 150 | 120 |
| DMC130 | 1 | 30 | 40 | 120 | 208/240 |
| DMA225 | 2 | 25 | 35 | 150 | 24 |
| DMB225 | 2 | 25 | 35 | 125 | 120 |
| DMC225 | 2 | 25 | 35 | 100 | 208/240 |
| Dma230 | 2 | 30 | 40 | 180 | 24 |
| DMB230 | 2 | 30 | 40 | 150 | 120 |
| Dmc230 | 2 | 30 | 40 | 120 | 208/240 |
| Dma240 | 2 | 40 | 50 | 240 | 24 |
| DMB240 | 2 | 40 | 50 | 200 | 120 |
| Dmc240 | 2 | 40 | 50 | 160 | 208/240 |
| DMA325 | 3 | 25 | 35 | 150 | 24 |
| DMB325 | 3 | 25 | 35 | 125 | 120 |
| DMC325 | 3 | 25 | 35 | 100 | 208/240 |
| Dma330 | 3 | 30 | 40 | 180 | 24 |
| DMB330 | 3 | 30 | 40 | 150 | 120 |
| Dmc330 | 3 | 30 | 40 | 120 | 208/240 |
| Dma340 | 3 | 40 | 50 | 240 | 24 |
| DMB340 | 3 | 40 | 50 | 200 | 120 |
| Dmc340 | 3 | 40 | 50 | 160 | 208/240 |
| Dma350 | 3 | 50 | 60 | 300 | 24 |
| Dmb350 | 3 | 50 | 60 | 250 | 120 |
| Dmc350 | 3 | 50 | 60 | 200 | 208/240 |
| DMA360 | 3 | 60 | 75 | 360 | 24 |
| DMB360 | 3 | 60 | 75 | 300 | 120 |
| Dmc360 | 3 | 60 | 75 | 240 | 208/240 |
| Dma375 | 3 | 75 | 93 | 450 | 24 |
| DMB375 | 3 | 75 | 93 | 375 | 120 |
| Dmc375 | 3 | 75 | 93 | 300 | 208/240 |
| Dma390 | 3 | 90 | 120 | 540 | 24 |
| DMB390 | 3 | 90 | 120 | 450 | 120 |
| Dmc390 | 3 | 90 | 120 | 360 | 208/240 |
